Insulation Plaster EXTERIOR

Wärmedämmputz Aussen

A ready-mixed facade insulation plaster containing Portland cement, expanded silicates and inorganic fillers. It is modified with additives, which are not harmful to health and environment, according to European filler directives and ISO requirements.It fulfils HEAT, SOUND and FIRE insulation conditions.

USAGE AREAS

It is used directly on the exterior walls of the buildings, columns and beams, on rough and fine plaster, brick, pumice bloc. Primer, must be used necessarily on concrete, gas concrete and painted surfaces

SURFACE PREPARATION

Blistered paint and spaced plasters are scraped off the surface. 4-5 notches per 10 cm² press on painted surfaces. The application surface should be cleaned from dust. Priming must be done on painted surfaces.

APPLICATION

Laths that determine the thickness are adhered to the prepared surfaces. Between two laths, is filled with a steel trowel or plasterer trowel and gauged. Following the first dry (~ 1-2 hours later ), the slats are removed from the surface and the spaces are filled and the pattern is drawn. if is dry when touched, (12-24 hours later) decorative plaster is drawn. No foreign matter should be added to the prepared mixture. (Lime, Plaster, Cement, etc.)

APPLICATION DETAILS

In manual application, it should be mixed with ~ 8-10 liters of water with low speed (400-600 rev/min) drill for 3-4 minutes. In machine application, it should be pumped to the surface by mixing with 8-10 liters of water in average. When the desired thickness is reached, it should be allowed to dry.

APPLICATION CONDITIONS

Application surface and ambient temperature should be above 5 °C. Considering excessive moisture loss at temperatures above 35 °C, mixing water should be increased and the surface should be kept moist by wetting for 1 day after the surface hardening phase.

ISSUES TO BE CONSIDERED

Avoid application under strong wind or sun. The time increases at low temperatures and the time decreases at high temperatures. It should not be applied on frozen, melting or freezing surfaces within 24 hours. Appropriate plaster mesh should be used at different material junctions and points where movement may be considered.

STORAGE TRANSPORT

Protect from frost, rain and other weather conditions. 70 Bags in 1 pallet is 3.500 L.

ENVIRONMENTAL IMPACTS

Not classified as dangerous.

Technicial Specifications

  • Packing
    50L / Bag ( ± 2 %)
  • Appearance
    White Powder
  • Application Temperature
    -5°C+30°C
  • Application Thickness
    10 mm – 50 mm
  • Application Time
    45 Minuten
  • Method of Application
    Steel Trowel-Pump
  • First Drying
    1 Hours
  • Setting Time
    72 Hours
  • Fire Response Class
    A1
  • Theoretical Powder Consumption
    14 – 16 L/m² /cm
  • Dry Density
    240 Kg/m³
  • Thermal Conductivity
    0,047 W/mK
  • Compressive Strength
    CSll (2,2 N/mm²)
  • Water vapor permeability
    8
  • Capillary Water Absorption
    W1
  • Adhesion Strength
    3,2 Kgf/cm
  • Sound Insulation (4cm Thickness)
    22 dB / 500 Hz
  • Fire Prevention (4cm Thickness)
    F120 / 120 Minutes
